Features:
Large effective filtration area, high flow rate, low pressure drop
Gradient aperture depth filtration guarantee Large dirt holding capacity, long service life,
Specifications:
Dimension:
Diameter:152mm
Length:20,40,60″
Material of Construction:
Media:PP / GF
Support layer:PP / PE
End Caps:PP / GF reinforced PP


Performance:
Max Operating Temperature:PP:80℃ / GF:121℃
Max Pressure Drop:3.5 bar @21℃
Recommended Change out Pressure drop:2.5bar@21℃
Max Flow rate: 40":70T/H    60":110T/H





Order Information  EG:LHFP5C40N
|
				 LHF  |

				 Filter Media  |

				 Pore Size  |

				 Appearance  |

				 Length  |

				 Seal Materials  |

|
				 P:PP  |

				 0.5:0.5um  |

				 B:Belt  |

				 20:20”  |

				 S:Silicone  |
		|
|
				 G:GF  |

				 1:1um  |

				 C:PP Cage  |

				 40:40”  |

				 E:EPDM  |
		|
|

  |

				 3:3um  |


  |

				 60:60”  |

				 N:Buna-N  |
		|
|

  |

				 5:5um  |


  |


  |

				 V:Viton  |
		|
|

  |

				 10:10um  |


  |


  |


  |
		|
|

  |

				 20:20um  |


  |


  |


  |
		|
|

  |

				 40:40um  |


  |


  |


  |
		|
|

  |

				 70:70um  |


  |


  |


  |
