Features:
Super High flow Performance.
100% PP , Wide chemical compatability
Thermal bonded without any chemical glue
FDA、NSF certified PP material

Product Specification:
Dimension:
            OD:152mm, 155mm
             ID:112mm, 115mm
             Length:10, 20, 30,40,50,60″
Material of Construction:
            Media : PP
Performance:
             Max Operating Temperature:65℃
             Max Operating DP:2 bar@21℃




 Order Information: EG:LDPHFA540
| LDPHF | Diameter | Pore Size | Length |
| A: ID: 112mm , OD:152mm | 1:1um | 10:10” | |
| B : ID: 115mm, OD:155mm | 3:3um | 20:20” | |
| 5:5um | 30:30” | ||
| 10:10um | 40:40” | ||
| 25:25um | 50:50” | ||
| 50:50um | 60:60” |
